Know the unit before the first shift.

A whole refinery in the browser. Every unit is a live P&ID, a 3D plant you can walk, a console you can upset, an operating manual and an Academy lesson behind every vessel. All of it runs off one set of numbers.

Book a demo Try CDU-100 yourself
CDU-100 · 3D EXPLORER
CDU-100 in the 3D explorer: atmospheric column, heater, strippers and pump row, every vessel opened to its internals Walk the Unit: at grade beside the P-101 crude charge pumps, reading the local pressure gauge on the field round The Refinery Unit Map: 22 units as one block flow with numbered inter-unit streams
22
refinery units, crude through blending
414
equipment items, each with a datasheet
507
instrument loops, each with a loop sheet
474
process streams with heat and material balance
105
failures walked step by step
66
detailed 3D equipment models
420+
assessment questions
WHAT'S INSIDE

Five views of every unit, one tag in all of them.

Every unit opens the same way, with one bar across the top. Pick H-101 on the drawing and it is the same H-101 in 3D, on the console, in the manual and in its Academy lesson. Trainees never have to ask which document is current.

P&IDThe drawing Trace a system, follow a stream, read a loop, walk a failure.
3DThe plant Explore the unit, open any vessel, then walk the field round at grade.
OPERATIONSThe job DCS console, startup and shutdown, cause and effect, troubleshooting.
MANUALThe reading A twelve-chapter operating manual written for each unit.
ACADEMYThe equipment Lessons on the equipment, instruments and streams inside each unit.
01 · THE P&ID

A drawing that answers back.

ISA symbols and real tag numbers, laid out the way your engineers draw them. Ask the sheet a question and it shows you the answer. Pick one below; the sheet on the right is the real page.

TRACE Heat recovery: pumparounds and preheat Open ↗

The CDU-100 sheet is live, but a P&ID needs more room than a phone gives it. Open it full screen instead.

Open the CDU-100 sheet
BEHIND EVERY TAG
The paperwork a trainee would otherwise hunt for, one click from the drawing.
507Loop sheets ISA-5.4 loop diagram from field to control room, alarm limits, fail positions and the loops each one works with.
414Equipment datasheets Design conditions, nozzles, materials and internals, opened from the item on the drawing or in 3D.
474Stream sheets Rate, phase, temperature, pressure and composition, with the route from source to destination.
22Build the sheet Place the equipment, trace the streams and place the loops from memory, scored on the finish.
02 · 3D

The same unit, standing up.

Every unit is built in 3D from the same equipment and stream tables as the drawing. Vessels are sized from their datasheets, every line lands on a real nozzle, and every vessel opens to show what is inside. Then put on the hard hat and walk it.

22 UNITS IN 3D LINES SIZED FROM THE STREAM TABLE EVERY LINE LANDS ON A NOZZLE CAGED LADDERS, PLATFORMS, MANWAYS 66 STANDALONE MODELS RUNS ON A TRAINING-ROOM LAPTOP
03 · OPERATIONS

Eight modules that put your people on shift.

The drawing teaches the unit; the Operator Workspace teaches the job. All eight modules ship on every one of the 22 units. CDU-100's are open here and running.

LIVE CDU-100 OPERATIONS · MODULE 04 · DCS CONSOLE Open ↗

All eight modules are live on CDU-100. The console and the matrix need room to work, so open them full screen.

Open the Operator Workspace
DCS console
WHAT THE TRAINER GETS
See it on your unit
04 · MANUAL & ACADEMY

The reading behind the drawing.

An operating manual for every unit, and an Academy that teaches the equipment, instruments and streams those units are made of, each lesson tied to the real tag on the real unit.

Fired heater lesson specialised to H-101 on CDU-100: the cabin firebox section with its ten parts, and the efficiency against excess oxygen curve
ACADEMY · H-101 FIRED HEATER, SPECIALISED TO CDU-100
CDU-100 in 3D with C-101 and the side strippers cut open to their trays, the column lines traced in orange
3D · C-101 AND THE SIDE STRIPPERS OPENED TO THEIR TRAYS
22MANUALS · 12 CHAPTERS EACH
Unit Operating Manual
Process description, principles, equipment, control, operating variables and limits, normal operation, startup and shutdown. Searchable, with engineering notes you can open or hide.
28EQUIPMENT LESSONS
Equipment Academy
How it works, when it fails, inspect and isolate, run it, in three dimensions, then a checkout. Each lesson is specialised to a real item, like H-101 on CDU-100.
663D EQUIPMENT MODELS
Models you can take apart
Pumps, compressors, columns, exchangers, reactors, heaters and valves, each cut open to its internals and tied back to the unit it stands in.
05 · ASSESSMENT & TRAINING

Know who can run it before they do.

Every exercise ends in a record you can review line by line, not just a pass mark. Instructors assign the steps; learners see only what they were assigned.

01
A knowledge check on every unit
Over 420 questions across 22 checks, in practice or assessment mode. Every answer links back to the vessel, loop or stream it tests.
02
Build the sheet from memory
Place the equipment, trace the streams, place the control loops. The finish report shows time, misplaced pieces, wrong turns and hints taken.
03
A score sheet from every module
Round sheets, challenge reports, the scored cause and effect matrix and the troubleshooting shift report.
04
Assignments and an instructor view
Instructors assign a unit at a level; the learner is kept to that step until it is done. Progress and results report to the Knowledge Library or your LMS.
CDU-100 KNOWLEDGE CHECK Open ↗

Take the CDU-100 knowledge check yourself. Every answer links back to the vessel, loop or stream it tests.

Open the knowledge check
ONE SET OF NUMBERS
The console, the manual and the question all say 690 °F.

Each unit is one engineering record: heat and material balance, alarm limits, relief sets, line sizes. Every view reads from it and every number is checked against it, so a trainee never finds the drawing and the board disagreeing.

P&ID
Loop note and stream table
690 °F
Loop sheet
Normal, alarms, fail position
690 °F
DCS console
Set point and alarm limits
690 °F
3D
Line sizes from the same streams
690 °F
Manual
Operating limits chapter
690 °F
Knowledge check
The question that tests it
690 °F
06 · THE UNITS

A whole refinery, crude through blending.

Including the utilities, relief, sulfur and effluent systems most libraries leave out. The Refinery Unit Map ties them together: every stream between units, traced. CDU-100 is open on this site; the rest are released with the library.

Refinery Unit Map: all 22 units as one block flow diagram with numbered inter-unit streams
07 · HOW IT STARTS

Start with one unit and your own experts.

01
A 30-minute walkthrough
We open CDU-100 with your training lead: the drawing, the 3D unit, a failure walked on the console, and how a class would use them.
02
Pilot one unit
Pick the unit your next new-hire class or turnaround is about. Your experts mark it up against the plant they run, and we apply their redlines.
03
Roll out
Deliver through the OEG Knowledge Library, or install the package in the LMS you already run and keep your reporting.
RUNS IN A BROWSER NOTHING TO INSTALL ONE URL PER UNIT DEEP LINKS TO ANY TAG VERSIONED RELEASES NIGHT THEME FOR THE CONTROL ROOM KNOWLEDGE LIBRARY OR YOUR LMS
08 Book a demo

See it on the unit your people run

Thirty minutes with your training lead

We cover CDU-100 end to end - the drawing, the 3D unit, Walk the Unit and the knowledge check - the Operations modules on the unit you pick, and what a one-unit pilot looks like at your site.
